S image of DKR04.1-W300N-BT71-02-FW

DKR04.1-W300N-BT71-02-FW

by Bosch Rexroth Indramat
$0.00 - $0.00
Request a Quote
$0.00 - $0.00
Request a Quote

Request a quote

Add a Message
Bosch Rexroth's DKR04.1-W300N-BT71-02-FW is a highly efficient drive controller that enables precise control of AC motors. This is primarily utilized in spindle motors, with a continuous power output between 10 and 93 kW. It is equipped with various interface cards for added versatility, which includes Profibus, INTERBUS, analog, and SERCOS interfaces. This wide-ranging speed drive controller provides continuous power supply, with enhanced control beneficial for use in printing machines or NC-controlled machine tools. Suitable for operation in ambient temperatures of +5° to +45° C and altitude up to 1000 m, the unit also houses a contactor and an emergency halt feature. The controller employs a heat sink and inbuilt blower for efficient cooling, which can accommodate both internal and external air sources. If space is constrained, the controller’s cooling system can be readjusted to utilize a duct system.

Contact Us

Email: sales@servosupplier.com
Phone Number: 1-888-551-3082
International: 1-919-443-0207
Fax: 1-919-867-6204

Servo Supplier is not an authorized distributor. We sell new surplus and refurbished products. All warranties are with Servo Supplier and not the manufacturer.

2 - 4 Days
Handling Time

30 Day Warranty

Shipping Options

Payment Options

Technical Specifications

Manufacturer

Bosch Rexroth Indramat

Product Type

Drive Controller

Model

DKR04.1-W300N-BT71-02-FW

Applicable Motors

Frameless spindle motors 1MB, main spindle motors 2AD or ADF, linear motors LSF or LAF

Motor Output Power

10 to 93 kW

Interface Options

Profibus interface, INTERBUS interface, analog interface, SERCOS interface

Usage

Printing machines, NC-controlled machine tools

Ambient Temperature for Operation

+5° to +45° C

Installation Elevation

0 to 1000 m above sea level

Power Supply

3xAC 400 V to 480 V

Cooling System

Blower and heat sink, offering adjustments for external/internal air

Emergency Features

Contactor and emergency stop shutdown device

Additional Features

Separate air intake and outlet for duct cooling if necessary.
