series image of DM 8K 9301-D

DM 8K 9301-D

by Bosch Rexroth Indramat
$1,473.00 - $1,473.00
$1,473.00
$1,473.00 - $1,473.00
$1,473.00
Available, Shipping Varies
The DM 8K 9301-D from Bosch Rexroth Indramat is a sophisticated drive controller designed for a wide range of industrial motors in high-demand production systems. Part of the Servodyn drive series, it adheres to an IP20 protection standard. However, it is recommended to be housed in a control cabinet for additional protection from dust, water, and other potentially damaging particles. This drive controller operates at a rated current of 1.1 Amperes and a DC link voltage of 670 volts, communicating via a CANopen and CANrho protocol. It is not suitable for use above temperatures of 45°C or elevations higher than 1000m above sea level. With optimal installation in a vertical position, this drive controller is ideal for high-power requirements industries like handling and packaging systems, robotics, and more. It satisfies the 3K3 climatic category per EN 60 721, has a maximum power loss of 96.5 watts, and weighs 6.0kg.
30 Day Warranty
Technical Specifications
  • Manufacturer: Bosch Rexroth Indramat
  • Product Type: Drive Controller
  • Model: DM 8K 9301-D
  • Series: Servodyn
  • Protection Category: IP20
  • Communication Protocol: CANopen and CANrho
  • Rated Current: 1.1 Amperes
  • DC link voltage: 670 volts
  • Maximum Ambient Temperature: 45 degrees Celsius
  • Maximum Elevation Level: 1000 meters above sea level
  • Storage Temperature: -25 to +70 degrees Celsius
  • Installation Position: Vertically with ports facing out
  • Suitable Operations: Handling systems, Packaging systems, Robotics, Other industrial operations with high power requirements
  • Climatic Category: 3K3 according to EN 60 721
  • Maximum Power Loss: 96.5 watts
  • Mass: 6.0 kilogram.
