DMA 15A 4101-D

Original price $10,656.25 - Original price $10,656.25
Original price
$10,656.25
$10,656.25 - $10,656.25
Current price $10,656.25
In Stock, Ships Today
Request a quote
Crafted by Bosch Rexroth Indramat, the DMA 15A 4101-D is a three-phase servo drive module featuring a Class A drive inverter. The product has an analog interface with a 16-bit resolution, allowing a +/-10V speed and a standard encoder interface. Its single-turn encoder carries a 20-bit resolution, which presents the actual position value. The unit operates at a rated current of 6.1Arms and can reach a maximum current of 18Arms at a frequency of 4kHz. With a 50mm width and weighing 7.3kg, it is a versatile choice for applications including CNC machining, automation and robotics. Best practices for usage include installation in dust-filtered switch cabinets and a waiting period of five minutes after disconnecting from the mains before removing covers. The inverter’s mechanics are optimized for power outputs and has a maximum current rating of 140A.
30 Day Warranty
Technical Specifications
  • Manufacturer: Bosch Rexroth Indramat
  • Product Type: Servo Drive Module
  • Model: DMA 15A 4101-D
  • Inverter Class: Class A
  • Speed Analog Interface: +/-10V (16-bit resolution)
  • Encoder Interface: Standard
  • Encoder Resolution: 20 bits
  • Rated Current: 6.1Arms
  • Maximum Current: 18Arms at 4kHz frequency
  • Width: 50mm
  • Weight: 7.3kg
  • Protection Rating: IP 20
  • Regulated DC link voltage: 670VDC
  • Maximum IGBT Output Stage Current: 140A
  • Speed Controller Cycle Time: 62.5μs
  • Current Controller Cycle Time: 62.5μs
  • Position Transmitting: Standard Encoder Simulation
