E0105-653-423

The Okuma E0105-653-423 operator control panel from the E5 Operator Panels series delivers a robust, industrial-grade human–machine interface designed for precision automation. Featuring a 10.4-inch TFT LCD display, the panel offers a 640 × 480 resolution and eight programmable soft keys for intuitive navigation and menu-based operation. Color or monochrome display modes are selectable via the DIP switch SW1-1 configuration, ensuring flexible visual feedback in diverse applications. Housed in a panel-mount enclosure with corner screw retention, this interface maintains reliable integration within machine control cabinets.

The panel’s technical specifications underline its industrial readiness: it operates at a rated voltage of 230 V and draws a current rating of 10 A at a frequency of 50 Hz. Its Display Type utilizes a TFT LCD cell that ensures consistent backlighting and viewing angles. The Display Size of 10.4 inches diagonal accommodates comprehensive data visualization, while the Resolution of 640 × 480 supports crisp alphanumeric and graphic content. Operator input is facilitated by 8 Soft Keys (F1–F8) and a dedicated Navigation Button for confirm/proceed actions. Environmental endurance is confirmed by an Operating Temperature range of –20 °C to +70 °C for continuous duty in fluctuating site conditions.

Designed for high-reliability operation, the panel features an Ingress Protection rating of IP66 that prevents dust and water ingress when mounted correctly. The Front Housing Material of industrial-grade plastic provides impact resistance without compromising weight or thermal performance. A Panel Mount with Corner Screws and embedded sealing frame guarantee stable attachment and maintain the IP66 barrier under mechanical stress. The DIP switch-configurable color/monochrome mode adds operational versatility, while the standard VGA interface enables analog video input alongside digital control signal connectors. Compact external dimensions minimize space requirements in control enclosures, making this panel suitable for complex assembly lines and mobile equipment.

System integration is streamlined through standardized connector layouts and compatibility with industry communication protocols. The panel’s reliability and durability make it ideal for CNC machine tools, industrial automation cells, packaging machinery, and metalworking centers. Its combination of high-contrast display, programmable function keys, and rugged construction positions the E0105-653-423 as a dependable solution for demanding manufacturing environments where uptime and operator efficiency are critical.
