S image of E22NRFT-JDN-NS-00

E22NRFT-JDN-NS-00

by Kollmorgen
$663.77 - $663.77
$663.77
$663.77 - $663.77
$663.77

Available, Shipping Varies

The E22NRFT-JDN-NS-00 from Kollmorgen features a NEMA 23 frame size and a holding torque of 236 oz-in. Part of the E Hybrid Stepper Motors series, it offers splashproof construction and a phase resistance of 0.29 Ohms. This motor delivers a rated current of 5.4 Amps and an insulation resistance of 100 MΩ at 500 V DC.

It generates an axial force of 180 lbs and a radial force of 35 lbs. The connector type is MS with an optional encoder. Shaft configuration is standard 4-lead with #18 AWG connections.

Contact Us

Email: sales@servosupplier.com
Phone Number: 1-888-551-3082
International: 1-919-443-0207
Fax: 1-919-867-6204

Servo Supplier is not an authorized distributor. We sell new surplus and refurbished products. All warranties are with Servo Supplier and not the manufacturer.

Military Grade
Packaging

30 Day Warranty

Shipping Options

Payment Options

Technical Specifications

Axial Force

180 lbs [801 N]

Connector Type

MS Connector with Encoder Option

Dimension L1 Max

6.73 inches [170.94 mm]

Dimension L2

5.61 inches [142.49 mm]

Front End Bell Configuration

Heavy Duty NEMA Front End Bell

Holding Torque (2 Phases On)

236 oz-in [1.67 Nm]

Insulation Bushing

Removable (0.56 I.D.)

Mounting Configuration

Standard Round Mounting (Not available on 3-stack Motor)

Phase Inductance

2.3 mH

Phase Resistance

0.29 Ohms

Radial Force

35 lbs [156 N]

Rated Current/phase

5.4 Amps

Shaft Configuration

Standard 4 lead motors with #18 AWG connections

Splashproof Construction

Available

Thermal Resistance

35 °C/Watt
