E34HCHT-LDK-NF-00

Name: E34HCHT-LDK-NF-00
Brand: Kollmorgen
Price: 825.0 USD
Availability: InStock

by Kollmorgen

$825.00 - $825.00

$825.00

$825.00 - $825.00

$825.00

In Stock, Ships 1 - 3 Days

The E34HCHT-LDK-NF-00 stepper motor from Kollmorgen’s E Hybrid Stepper Motors series delivers a maintenance-free design and compact size ideal for industrial automation. It features a NEMA 34 conventional frame, a holding torque of 8.76 Nm, IP65 ingress protection, and a thermal resistance of 35°C/W. The motor reaches a maximum length of 193.60 mm, offers configurable splash-proof construction, and supports DFlat and #303 Woodruff Key shaft types. It operates reliably from -20°C to +40°C and utilizes SIGMAX technology.

Contact Us

Email: sales@servosupplier.com

Phone Number: 1-888-551-3082

International: 1-919-443-0207

Fax: 1-919-867-6204

Servo Supplier is not an authorized distributor. We sell new surplus and refurbished products. All warranties are with Servo Supplier and not the manufacturer.

Military Grade
Packaging

30 Day Warranty

Shipping Options

Payment Options

Technical Specifications

Electrical Lead Connection

Lead Hookup

Encoder Connection Hole Diameter

Ø 2.186 inches ± .002 [55.52 ± 0.051 mm]

Encoder Depth

.33 inches [8.38 mm] maximum

Encoder Mounting Option Availability

Not available on 3 stack motor

Maximum Encoder Length (l2)

6.86 inches [174.24 mm]

Maximum External Motor Diameter

2.22 inches [56.39 mm]

Maximum Motor Length (l1)

7.62 inches [193.60 mm]

Maximum Radial Force

43.69 mm [1.72 inches]

Maximum Shaft Length

.875 inches ± .010 [22.23 ± 0.025 mm]

Rotor Inertia

0.0083 oz-in-s2 [0.0586 × 10^(-3) kg-m2]

Shaft Loading Radial Force

180 lbs [801 N]

Shaft Type Configurations

DFlat, F, and #303 Woodruff Key

Splash proof Construction Availability

Yes, configurable

System Construction

MS connector with encoder option

Thermal Resistance

35°C/Watt
