The B & R Automation ECPNC3-1 is a precision encoder module in the ECP Multi Control Modules series. It features a 9-pin D-type female encoder connector, supports a maximum 50 m cable run, a 200 kHz counting frequency with 4-fold evaluation, 10-bit+sign resolution and ±10 V analog output. Operating on 512 VDC, it handles input frequencies up to 50 kHz for reliable industrial automation control.
Servo Supplier is not an authorized distributor. We sell new surplus and refurbished products. All warranties are with Servo Supplier and not the manufacturer.
Analog Output
±10 V
Counting Frequency
max 200 kHz
Counting Range
24 bit
Distance to Encoder
max 50 m
Encoder Supply
5 VDC/250 mA or 15 VDC/500 mA
Evaluation Mode
4-fold
Galvanic Isolation
No
Input Current @15 VDC
typ 5 mA
Input Current @5 VDC
typ 2 mA
Input Frequency
max 50 kHz
Input Voltage Range
2.4-15 VDC
Nominal Input Voltage
5-12 VDC
Phase Shift A/B
90°±30°
Quantization Error
<1 bit
Reference Pulse Duration
>50 µs
Resolution
10 bit + sign
Signal Encoder Connector
9-pin D-type (F)
