ECPP40IF4-01
The ECPP40IF4-01 from B & R Automation represents a high-performance inductive proximity sensor within the ECP Multi Control Modules series. This precision device offers a Detection Distance of 4 mm and operates on a Supply Voltage range of 10 to 30 VDC, ensuring broad compatibility across industrial control systems. Designed as an Inductive Proximity Sensor, it detects metallic targets with reliable accuracy and minimal wear. Packaged in a robust nickel-plated brass housing, the sensor is engineered for both durability and compact integration. Its Installation profile supports flush mounting, allowing seamless incorporation into existing machinery layouts.
Featuring advanced technical capabilities, the ECPP40IF4-01 provides a PNP Normally Open (NO) Output Type that integrates directly with standard PLC logic. A rapid Response Frequency of 1 kHz allows the sensor to track high-speed motion without signal loss or lag. It sustains a Max Load Current of ≤ 200 mA while maintaining a low Current Consumption of ≤ 20 mA, optimizing energy efficiency in continuous operation. Built-in Protection Circuit safeguards against short-circuits and reverse polarity, increasing system uptime and reducing maintenance. Connection is achieved via a pre-wired Connection Type cable, streamlining installation and minimizing configuration time.
Operationally, the sensor’s Degree Of Protection rating of IP67 certifies complete immunity to dust ingress and transient water immersion, making it suitable for harsh shop-floor environments. The housing material of Nickel-plated Brass delivers exceptional mechanical resilience against impacts and corrosive conditions. With an Operating Temperature range from –25 °C to +70 °C, the device performs reliably across extreme manufacturing and processing applications. Its Sensing Object specification for metal targets ensures precise detection in automated assembly, material handling, and safety monitoring. Flush mount capability prevents protrusion into active work areas, reducing the risk of accidental damage and maintaining consistent sensing geometry.
Integration of the ECPP40IF4-01 into complex automation architectures is straightforward thanks to its industry-standard interface and compact footprint. The sensor’s robust design and extensive technical specification make it ideal for critical applications such as conveyor tracking, packaging lines, and machining centers. Manufacturers benefit from the one-year Warranty backing, ensuring long-term confidence and support. As part of the ECP Multi Control Modules series, this sensor enhances system modularity, simplifies inventory management, and accelerates commissioning in diverse industrial settings.
