ECPTE8-3
The ECPTE8-3 from B & R Automation’s ECP Multi Control Modules series is a precision-engineered compression lug designed for robust industrial connections. This module features a non-insulated design crafted from high-conductivity copper with durable electro tin plating that ensures long-lasting corrosion resistance. Rated for 600V service and capable of handling temperatures up to 90°C, it reliably accommodates 8 AWG conductors through its standard barrel configuration. With CSA certification and a compact overall length of 1.38 inch (35.1 mm), this terminal offers a perfect balance of performance and size for diverse installation environments.
Technical capabilities of the ECPTE8-3 emphasize reliability and ease of use in demanding electrical systems. The standard barrel accepts 8 AWG wire for optimal current-carrying capacity while maintaining low resistance for efficient power distribution. Its compression lug design features a 1/4" stud size that secures a firm mechanical and electrical bond when properly crimped with industry-standard tools. The electro tin plating enhances contact integrity and shields the copper substrate from oxidation even under high-humidity or corrosive conditions. A bright red color code simplifies wire identification during assembly and maintenance.
Operational features of the ECPTE8-3 deliver tangible benefits in both performance and safety. The non-insulated construction provides visible confirmation of crimp quality and supports effective heat dissipation during heavy current flows, reducing thermal buildup. Certified to CSA standards, this lug meets stringent requirements for electrical safety and dimensional accuracy. Its temperature rating of up to 90°C ensures stable operation in moderately elevated thermal environments without material degradation. The sturdy copper body withstands mechanical stresses, while the tin plating maintains long-term conductivity and resists surface corrosion.
Integration of the ECPTE8-3 into power distribution panels, grounding networks, and switchgear assemblies is straightforward and dependable. Its compact overall length of 1.38 inch (35.1 mm) and 1/4" stud size are compatible with standard bus bars and terminal blocks, streamlining retrofits and new installations. Engineers leverage its certified performance and color-coded identification to optimize wire routing and reduce assembly time. Ideal for industrial automation, electrical control cabinets, and renewable energy systems, the ECPTE8-3 offers consistent, high-quality connections that support system uptime and maintenance efficiency.
