P image of EEA-PAM-523-D-32

EEA-PAM-523-D-32

by Vickers
$2,707.09 - $2,707.09
$2,707.09
$2,707.09 - $2,707.09
$2,707.09

In Stock, Ships Fast

The Eaton EEA-PAM-523-D-32 power amplifier, sold under the Vickers brand, is a robust part of Eaton's D series. With the potential to replace two standard electronic cards, the unit features an inbuilt ramp generator, command input ramps, and an integrated PID module. Its Eurocard-style design facilitates quick installation, and the amplifier carries a CE Certification, suitable for global deployment via dependable delivery partners. Despite bearing similarities to the manufacturer's A series, it falls short of the A series' gain factor; it compensates for this with an analog feedback sensor interface. The device, primarily utilized in closed-loop pressure control applications with proportional pressure valves, boasts minimal external wiring and a user-configurable PID feed-forward operation. Additionally, the amplifier comprises nine configurable DIL switches, input current range from 0mA-20mA or 4mA-20mA, a 24VDC input power supply, and an indicator LED for enabled ramps. Compatible with KDG5V-5/7/8 and K*G4V-3 valves with H coils, the amplifier also incorporates a 6-kilo Ohm feed-forward input impedance and short circuit-protected analog output feedback signal. An alarm signal activates at a peak current rating of 50mA.

Contact Us

Email: sales@servosupplier.com
Phone Number: 1-888-551-3082
International: 1-919-443-0207
Fax: 1-919-867-6204

Servo Supplier is not an authorized distributor. We sell new surplus and refurbished products. All warranties are with Servo Supplier and not the manufacturer.

2 - 4 Days
Handling Time

30 Day Warranty

Shipping Options

Payment Options

Technical Specifications

Manufacturer

Eaton

Brand

Vickers

Product Type

Power Amplifier

Model Number

EEA-PAM-523-D-32

Design

Eurocard

CE Certified

Yes

Replaces

Two standard electronic cards

Additional Features

Integrated PID modules, Ramp generator

Feedback Sensor Interface

Analog

Application

Closed-loop pressure control applications

Wiring

Minimum external wiring

Operations

User-configurable PID feed-forward operation

Configurable Switches

9 DIL switches

Input Current

0-20mA or 4-20mA

Input Power Supply

24VDC

Panel Indicator

Yellow LED

Valve Compatibility

KDG5V-5/7/8 and K*G4V-3 valves with H coils

Feed-forward Input Impedance

6kilo Ohms

PID Controller Voltage Range

0-3.5V (when disabled)

Output Protection

Short circuit protection

Alarm Signal

Activated to HIGH at maximum 50mA current rating.
