The Beckhoff EJ2809-0000 is a 16-channel digital output EtherCAT plug-in module from the EJ EtherCAT Plugins series. Operating at 24 V DC, each channel delivers 0.5 A with reverse voltage protection and short-circuit proof outputs. Conforming to EN 61000-6-2/6-4 and weighing 30 g, it supports ohmic, inductive, and lamp loads.
Servo Supplier is not an authorized distributor. We sell new surplus and refurbished products. All warranties are with Servo Supplier and not the manufacturer.
Auxiliary Power Current
typ. 30 mA + load
Breaking Energy
< 150 mJ/channel
Current Consumption E-bus
typ. 110 mA
Emc Immunity/emission
conforms to EN 61000-6-2/EN 61000-6-4
Load Type
ohmic, inductive, lamp load
Max. Output Current
0.5 A (short-circuit proof) per channel
Number Of Outputs
16
Operating/storage Temperature
-25…+60°C/-40…+85°C
Protection Rating/installation Position
IP20/see documentation
Rated Load Voltage
24 V DC (-15%/+20%)
Reverse Voltage Protection
yes
Short-circuit Current
typ. < 2 A
Switching Times
typ. T_ON: 60 µs, typ. T_OFF: 300 µs
Vibration/shock Resistance
conforms to EN 60068-2-6/EN 60068-2-27
Weight
approx. 30 g
