EK1101

Original price $852.00 - Original price $852.00
Original price
$852.00
$852.00 - $852.00
Current price $852.00
Available, Shipping Varies
Request a quote
The Beckhoff EK1101 EtherCAT Coupler is a vital component for connecting Beckhoff I/O stations to an external EtherCAT network for communication with other devices such as IPCs, PLCs, or motion controllers. Equipped with two RJ45 sockets and an E-bus connection, the EK1101 simplifies the connectivity for high-performance automation applications. Notably, it supports the HotConnect procedure, allowing the extension of network branches that can be modified even during operations. The three rotary switches at the back are responsible for setting the device's ID. Additionally, the EK1101 comes with the capability to provide up to 2000 mA to the connected terminals, which can be further supplemented with additional Power Feed Terminals if more current is required. This device serves to uphold Beckhoff’s reputation as an industry leader for industrial technology drive by standardizing EtherCAT as its fieldbus and communication protocols for these products.
30 Day Warranty
Technical Specifications
  • Manufacturer: Beckhoff
  • Product Type: EtherCAT coupler
  • Model: EK1101
  • Connection Method: RJ45 sockets, E-bus connection
  • Support: HotConnect EtherCAT procedure
  • Settings: Three rotary switches (ID range 1 to 65535)
  • Placement: Any position in the network
  • Power Supply: Up to 2000 mA to the station
  • Additional Requirement when More Power is Needed: Installation of additional Power Feed Terminals (e.g: EL9400, EL9401)
