S image of EK1101-0010

EK1101-0010

by Beckhoff
$585.15 - $962.47
$585.15
$585.15 - $962.47
$585.15
The EK1101-0010, crafted by Beckhoff, is an EtherCAT coupler that plays a pivotal role in linking EtherCAT terminals with EtherCAT device protocols. The device, furnished with an RJ45 socket, plays a pivotal role in the conversion of telegrams from the Ethernet 100BASE-TX into the E-bus signal format, minimising latency. For seamless data transfer, it utilises EtherCAT/Ethernet 22AWG shielded copper cables. It facilitates the HotConnect procedure and supports a station with unlimited EtherCAT terminals. The device identifies each EtherCAT component group using a unique ID. The robust polycarbonate housing encompasses an LED signal indicator and has dimensions of 44 x 100 x 68mm. The EK1101-0010 showcases three spring power contacts and can withstand a temperature range of -25°C and +85°C. It is CE certified, has a data transfer rate of 100Mbits/s and a maximum current rating of 2000mA on the E-bus. The device supports a maximum distance of 300m between two stations.

Contact Us

Email: sales@servosupplier.com
Phone Number: 1-888-551-3082
International: 1-919-443-0207
Fax: 1-919-867-6204

Servo Supplier is not an authorized distributor. We sell new surplus and refurbished products. All warranties are with Servo Supplier and not the manufacturer.

Military Grade
Packaging

30 Day Warranty

Shipping Options

Payment Options

Technical Specifications

Manufacturer

Beckhoff Automation GmbH

Product Type

EK1101-0010 EtherCAT Coupler

Connector Type

RJ45 Socket

Device Compatibility

EtherCAT Terminals and Device Protocols

Station Support

Coupler, Bus-end Terminal and Unlimited EtherCAT Terminals

Conversion

From Ethernet 100BASE-TX format to E-bus Signal Format

Special Features

Implementation of HotConnect procedure

Cable Type

EtherCAT/Ethernet 22AWG Shielded Copper Cables

Housing

Polycarbonate Compact Terminal Housing with Signal LED

Connection Wires Stripping Length

8-9mm

EMC Resistance

EN 61000-6-2 Specification Conformance

Housing Size

44 x 100 x 68mm (W x H x D)

Topology Support

Multiple Topologies without Configuration

Configurable IDs

Maximum of 4096

Electrical Isolation Voltage Rating

500V

Storage Temperature

-25°C to +85°C

Certification

CE Certified

Data Transfer

Rate 100Mbits/s

Vibration Resistance

EN60068-2-6 Specification Conformance

Distance Support

Maximum 300m between two stations

E-bus Current Rating

Maximum 2,000mA.
