P image of EK1110

EK1110

by Beckhoff
$516.24 - $567.86
$567.86
$516.24 - $567.86
$567.86

In Stock, Ships 1 - 3 Days

The Beckhoff EK1110 is an EtherCAT extension of the EK product range that is installed at the end of the EtherCAT Terminal Block. Capable of electrically isolating Ethernet CAT 5 cables up to 100m through an RJ 45 connector, the EK1110's primary role is the conversion of E-bus signals to a 100BASE_TX Ethernet signal, powered by the E-bus itself. The device houses a 100 Mbaud baud rate and is ready-to-use without requiring an address or preliminary settings. Offering a usage delay of 1 microsecond, the EK1110 operates with a dielectric strength of 500 V and a typical current consumption of 130mA. Designed to function within a temperature range of -25oC to +60oC, with a storage range of -40oC to +85oC, the EK1110 is humidity resistant up to 95%, excludes condensation, and complies with the IP20 protection class. Its measurements are 44mm x 100mm x 68mm and it approximately weighs 50g. The EK1110 is CE, ATEX, and cULus approved.

Contact Us

Email: sales@servosupplier.com
Phone Number: 1-888-551-3082
International: 1-919-443-0207
Fax: 1-919-867-6204

Servo Supplier is not an authorized distributor. We sell new surplus and refurbished products. All warranties are with Servo Supplier and not the manufacturer.

2 - 4 Days
Handling Time

30 Day Warranty

Shipping Options

Payment Options

Technical Specifications

Product Family

EK

Manufacturer

Beckhoff

Product Type

EtherCAT Extension

Mounting Location

End of EtherCAT Terminal Block

Primary Function

Extend EtherCAT strand by up to 100m

Electrical Interface

RJ 45 connector

Secondary Function

Convert E-bus signal to 100BASE_TX Ethernet

Power Source

E-bus

Transmission Medium

Shielded Ethernet CAT 5 cable

Max Cable Length

100m between two Bus Couplers

Baud Rate

100 Mbaud

Protocol Compatibility

All EtherCAT protocols

Configuration Requirement

None

Signal Delay

1 microsecond

Dielectric Strength

500 V

Current Consumption

Typ. 130mA

Operating Temperature Range

-25oC to +60oC

Storage Temperature Range

-40oC to +85oC

Permissible Humidity

95%, absence of condensation

Mounting

35 mm mounting rail

Vibration and Shock Resistance

EN 60068-2-6/EN 60068-2-27

Protection Class

IP20

Installation Position

Variable

Dimensions

44 mm x 100 mm x 68 mm

Weight

Approximately 50 g

Approval Certificates

CE, ATEX, cULus-
