C image of EK1122 | Main (Front Left)

EK1122

by Beckhoff
$452.22 - $646.70
$452.22
$452.22 - $646.70
$452.22
The EK1122 EtherCAT Junction is a product developed by automation systems leader Beckhoff. Renowned for its effectiveness, reliability, and simplicity, this junction uses Ethernet 100Base-TX (min. CAT5) with two RJ45 bus connections for transmission. Weighing approximately 70g with dimensions of 26mm x 100mm x 52mm, this durable unit operates efficiently within an ambient temperature of -25°C to 85°C. Enabled for a variety of topologies, including star, line and tree, its power supply comes from the E-bus, consuming only 220mA of current. The EK1122 offers vibration resistance conforming to EN 60068-2-6 and EMC immunity that aligns with EN 61000-6-2. Furthermore, the unit has an IP20 protection class to safeguard against dust or water. Installation is flexible with its ability to secure onto any 35mm mounting rail, promising adaptability within various industrial environments. It also features three diagnostic LEDs for enhanced operation monitoring.

Contact Us

Email: sales@servosupplier.com
Phone Number: 1-888-551-3082
International: 1-919-443-0207
Fax: 1-919-867-6204

Servo Supplier is not an authorized distributor. We sell new surplus and refurbished products. All warranties are with Servo Supplier and not the manufacturer.

Military Grade
Packaging

30 Day Warranty

Shipping Options

Payment Options

Technical Specifications

Manufacturer

Beckhoff

Product Type

EtherCAT Junction

Model

EK1122

Transmission Medium

Ethernet 100Base-TX (min. CAT5)

Bus Connections

2 RJ45

Power Supply

From E-bus

Current Consumption

220mA

Weight

70g

Dimensions

26mm x 100mm x 52mm (W x H x D)

Operating Temperature

-25˚C to 85˚C

Relative Humidity

95% (no condensation)

Topologies

Star, Line, Tree

Vibration Resistance

Conforms to EN 60068-2-6

EMC Immunity

Conforms to EN 61000-6-2

Protection Class

IP20

Mounting Options

35mm Mounting Rail

Diagnostics

3 LEDs (Fieldbus diagnostics, Link/Act (X1/X2))

Recommendations for Cabling

Not to exceed 100m between devices.
