EK1818

Original price $539.67 - Original price $980.24
Original price
$539.67
$539.67 - $980.24
Current price $539.67

In Stock, Ships 1 - 3 Days

The Beckhoff Automation GmBH's EK1818 EtherCAT coupler, belonging to the EK1800 series, is a versatile device furnished with eight digital inputs and four digital outputs. The product boasts a commendable data transfer speed of 100Mbaud. Fitted with multiple diagnostic LEDs, this unit ensures efficient monitoring of power supply, EtherCAT state machine/PLC, Fieldbus, and digital inputs or outputs. The EK1818 EtherCAT coupler, strictly designed to be used in conjunction with Beckhoff’s UL Listed EtherCAT system, has a short-circuit current rating of less than 2A. With an IP 20 protection rating, this coupler supports the connection of various terminals through its right side and a high-level network via the left side. The device is equipped to handle ferrule, stranded wire, and solid wire type conductors and enforce reverse polarity protection. With a power supply rating of 24VDC, the EtherCAT coupler is viable for an operating temperature range of -25°C to 60°C. Please note that the coupler can't be used with a switch or router.

Contact Us

Servo Supplier is not an authorized distributor. We sell new surplus and refurbished products. All warranties are with Servo Supplier and not the manufacturer.

Military Grade
Packaging

30 Day Warranty

Shipping Options

Payment Options

Technical Specifications

Product


EK1818 EtherCAT coupler

Manufacturer


Beckhoff Automation GmbH

Product Series


EK1800

Digital Outputs


4

Digital Inputs


8

Data Transfer Rate


100Mbaud

LED Diagnostics


Yes

UL Listed EtherCAT System Compatible


Yes

Firmware


None

Short Circuit Current Rating


Less than 2A

Protection Rating


IP 20

Switch or Router Compatibility


No

E-bus Electrical Isolation Voltage


500V

Supported Conductors


Ferrule, stranded wire, solid wire

Reverse Polarity Protection


Yes

Power Supply Rating


24VDC

Installation Position


Any

Operating Temperature


-25°C to 60°C

Time Delay


1µs

Mounting


Fits on a mounting rail

Electrostatic Discharge Sensitivity


Yes

Output Current per Channel


0.49A maximum

Ferrule Conductor Cross-section


0.14 to 0.75 sq.mm

Vibration Resistance


EN60068-2-6 compliant
