S image of EK1818-0000

EK1818-0000

by Beckhoff
$1,494.90 - $1,644.39
$1,494.90
$1,494.90 - $1,644.39
$1,494.90

The EK1818-0000 from Beckhoff features two RJ45 interfaces and supports 100 Mbit/s transfer. Part of the EK EtherCAT Coupler Series, it links up to 65,534 terminals via shielded Cat.5 Ethernet/EtherCAT cable. This coupler offers eight digital inputs and four digital outputs and includes automatic EtherCAT detection.

It draws 100 mA on the system bus plus E-bus current and 40 mA on the upstream bus while supplying 24 V DC at 1000 mA. Max station distance is 100 m. Operating temperature range is -25 to 60 °C.

Contact Us

Email: sales@servosupplier.com
Phone Number: 1-888-551-3082
International: 1-919-443-0207
Fax: 1-919-867-6204

Servo Supplier is not an authorized distributor. We sell new surplus and refurbished products. All warranties are with Servo Supplier and not the manufacturer.

Military Grade
Packaging

30 Day Warranty

Shipping Options

Payment Options

Technical Specifications

Bus Interface

2 × RJ45

Current Consumption (System Bus)

100 mA + (Σ E‑bus current/4)

Current Consumption (Upstream Bus)

40 mA + load

Data Cable Medium

Ethernet/EtherCAT cable, shielded (Cat.5 min.)

Data Transfer Rate

100 Mbit/s

E‑bus Supply Current

1000 mA

Function within EtherCAT System

Coupling ELxxxx terminals to 100BASE‑TX EtherCAT

Max Distance Between Stations

100 m

Max Number of EtherCAT Terminals

65,534

Number of Inputs

8

Propagation Delay

approx. 1 µs

Protocol

EtherCAT

Signal Voltage

-3…+5 V (EN 61131‑2 type 1/3)

Supply Voltage

24 V DC (‑15%/+20%)
