The EL5042 is a 2-channel encoder interface terminal from Beckhoff’s EL EtherCAT Terminals series, offering 64-bit position resolution and supporting 5 V or 9 V DC encoder operating voltage. Equipped with distributed clocks, adjustable baud rates and adjustable data lengths, it delivers up to 10 MHz data transfer. With a weight of 50 g, it operates at 0…+50 °C and consumes only 150 mA via 24 V DC.
Servo Supplier is not an authorized distributor. We sell new surplus and refurbished products. All warranties are with Servo Supplier and not the manufacturer.
Adjustable baud rate
yes
Adjustable data length
yes
Data transfer rate
up to 10 MHz
Distributed clocks
supported
E‑bus current consumption
typ. 120 mA
Encoder connection
D+, D-, C+, C-
Encoder supply current
max. 0.5 A total
Encoder supply voltage
5 V DC or 9 V DC
Number of channels
2
Operating temperature
0…+50 °C
Power contact current consumption
typ. 150 mA + load
Resolution
64‑bit position, 2‑bit status, 8‑bit CRC
Status bits evaluation
separate error and warning
Storage temperature
-25…+85 °C
Supply voltage electronics
24 V DC
Weight
approx. 50 g
