P image of EL6601

EL6601

by Beckhoff
$471.03 - $803.69
$471.03
$471.03 - $803.69
$471.03

In Stock, Ships 1 - 3 Days

The Beckhoff EL6601 product is an Ethernet switch terminal designed for the integration of distributed Ethernet devices within an industrial setting. This terminal facilitates collision-free communication between EtherCAT network devices, with no need for configuration. The device features a single 10BASE-T/ 100BASE-TX Ethernet port and provides automatic detection of crossed lines and baud rate. The EL6601 operates efficiently within a temperature range of -25 to 60 degrees Celsius, with a storage temperature range of -40 to 85 degrees Celsius. Additionally, the terminal displays operational statuses including Run and Ethernet error through an LED interface. Its power source is the E-bus with an average current consumption of 310 mA and it offers 500 V isolation between the E-bus and IP 20 Ethernet connections. The device supports network variables and is designed to operate optimally in an environment with a non-condensing relative humidity of up to 95%.

Contact Us

Email: sales@servosupplier.com
Phone Number: 1-888-551-3082
International: 1-919-443-0207
Fax: 1-919-867-6204

Servo Supplier is not an authorized distributor. We sell new surplus and refurbished products. All warranties are with Servo Supplier and not the manufacturer.

Military Grade
Packaging

30 Day Warranty

Shipping Options

Payment Options

Technical Specifications

Manufacturer

Beckhoff

Product Type

Switch Terminal

Model

EL6601

Use

EtherCAT terminal network

Ethernet Connection

Yes

Ethernet Ports

1

Ethernet Interface

10BASE-T/ 100BASE-TX

Operating Temperature

-25 to 60 degrees Celsius

Storage Temperature

-40 to 85 degrees Celsius

Data Transfer Rate

10/100 Mbits per second

Status Indicators

Run and Ethernet error LEDs

Supports Network Variables

Yes

Power Source

E-bus

Current Consumption

310 mA

Electrical Isolation

500 V between E-bus and Ethernet

Relative Humidity

95% non-condensing
