P image of EL6632

EL6632

by Beckhoff
$1,633.75 - $2,312.95
$1,633.75
$1,633.75 - $2,312.95
$1,633.75
The Beckhoff EL6632 is a high-functioning PROFINET IRT controller designed for robust industrial operations. It effectively transforms a PC-based control system into a PROFINET IO controller using a Beckhoff TwinCAT supplement for optimal interfacing. Moreover, the terminal can interface between PROFINET and EtherCAT networks, acting as a controller for PROFINET and a slave for EtherCAT. This device is equipped with status LEDs for easy monitoring and troubleshooting, and it supports a maximum of 15 PROFINET RT devices and 5 PROFINET IRT devices. Network diagnostics are conducted using SNMP or LLDP protocols. The EL6632 is compatible with Windows XP and Windows XP Embedded operating systems, and uses TwinCAT software for operation. The controller boasts a 500 V electrical isolation capacity for optimal safety, and it functions best at a temperature range of 0 to 55 degrees Celsius with a relative humidity of 95% without condensation.

Contact Us

Email: sales@servosupplier.com
Phone Number: 1-888-551-3082
International: 1-919-443-0207
Fax: 1-919-867-6204

Servo Supplier is not an authorized distributor. We sell new surplus and refurbished products. All warranties are with Servo Supplier and not the manufacturer.

Military Grade
Packaging

30 Day Warranty

Shipping Options

Payment Options

Technical Specifications

Product Name

Beckhoff EL6632 PROFINET IRT Controller

Function

Turns each Beckhoff PC-based control system into a PROFINET IO controller

Maximum PROFINET RT devices supported

15 Devices

Maximum PROFINET IRT Devices Supported

5 Devices

Connected in Line Topology

Yes

Maximum Distance Between Two Devices

100 Meters

Network Diagnostics

SNMP or LLDP Protocols

Supported Operating Systems

Windows XP, Windows XP Embedded

Supported Software

TwinCAT I/O, CNC, NC I, NC, PLC

Target Systems

PC (x86), Windows CE devices with an EtherCAT interface

Electrical Isolation for the E-bus/Ethernet

500V

Minimum Isochronous Real-Time Cycle

500 Microseconds

Minimum Real-Time Cycle

1 Millisecond

Current Consumption

400 mA via E-bus

Operating Temperature

0 to 55 Degrees Celsius

Storage Temperature

-25 to +85 Degrees Celsius

Relative Humidity

95% without condensation.
