The EL6695-0000 by Beckhoff is an EtherCAT bridge from the EL EtherCAT Terminals series featuring 2 x 100 Mbit/s RJ45 ports and support for distributed clocks. Powered by the E-bus (400 mA) with an optional 24 V supply (70 mA), it offers status LEDs for hardware diagnostics, flexible PDO mapping, up to 100 m cable length, IP20 protection, and weighs just 75 g operating from 0 to +55°C.
Servo Supplier is not an authorized distributor. We sell new surplus and refurbished products. All warranties are with Servo Supplier and not the manufacturer.
AoE/EoE/FoE/VoE support
Yes
Approvals/Markings
CE, UL
Cable length (secondary port)
100 m (100BASE-TX)
Current consumption (24 V supply)
70 mA
Current consumption (E-bus)
400 mA
Data exchange features
synchronous; flexible PDO mapping
Distributed clocks
Yes
EMC immunity/emission
EN 61000-6-2 / EN 61000-6-4
Hardware diagnostics
status LEDs
Installation position
variable
Operating temperature
0 to +55°C
Ports
E-bus; 2 x RJ45 EtherCAT I/O
Power supply
E-bus; 24 V via connector
Process image bit width
max. 3 kByte per direction
Protection rating
IP20
Storage temperature
-25 to +85°C
TwinCAT reference clock support
Yes
Vibration/shock resistance
EN 60068-2-6 / EN 60068-2-27
Weight
approx. 75 g
