EL6900

Original price $473.64 - Original price $521.00
Original price
$473.64
$473.64 - $521.00
Current price $473.64

In Stock, Ships 1 - 3 Days

The EL6900 TwinSAFE Logic Terminal is a product from German company, Beckhoff Automation Technology, and acts as a bridge between TwinSAFE digital input and output terminals. Light and compact, it weighs 50 grams with dimensions of 12 mm x 100 mm x 68 mm (W x H x D). The terminal's facade includes eight LEDs for status indication and diagnostic purposes, and eight connection slots for input devices. Running on 24 VDC, the EL6900 has a minimum cycle time of 500 microseconds and an error reaction time ranging from 2ms to 60000ms, with a power dissipation of approximately 1W. It is vibration/shock resistant and EMC immune, meeting UL, IEC, EN, NRTL, and ISO safety standards. For optimal convection cooling, keep a necessary distance between the terminal and control cabinet walls or adjacent devices.

Contact Us

Servo Supplier is not an authorized distributor. We sell new surplus and refurbished products. All warranties are with Servo Supplier and not the manufacturer.

Military Grade
Packaging

30 Day Warranty

Shipping Options

Payment Options

Technical Specifications

Manufacturer


Beckhoff

Product


EL6900 TwinSAFE Logic Terminal

Company Origin


Germany

Use Case


Link between TwinSAFE digital input and output terminals

TwinSAFE Connections


Up to 128

Safety Standards


UL, IEC, EN, NRTL, ISO

Weight


50 grams

Dimensions


12 mm x 100 mm x 68 mm (W x H x D)

Design


Typical EtherCAT Terminal

LEDs


8 for status-indication and diagnosis

Input Slots


8

Minimum Cycle Time


500 microseconds

Error Reaction Time


2ms to 60000ms

Operating Voltage


24 VDC

Current Consumption


188mA via E-bus

Power Dissipation


Approximately 1W

Protection


Dust and dirt resistance

Environmental Standards


EN standards for vibration/shock resistance and EMC immunity/emission

Cooling Requirements


Optimal convection cooling when sufficient distance is maintained with control cabinet walls.
