EL7211-9014

Original price $1,459.00 - Original price $1,459.00
Original price
$1,459.00
$1,459.00 - $1,459.00
Current price $1,459.00
In Stock, Ships 1 - 2 Days
Request a quote
The EL7211-9014 EtherCAT Servo Terminal, specially designed for BECKHOFF's AM8100 series synchronous servomotors, allows for torque or speed-oriented motor control. Using its One Cable Technology (OCT), it significantly reduces the cabling necessary for a motion control system. The servo terminal is also user-friendly, automatically identifying the attached motor type and parameters. It is capable of high-speed and dynamic control tasks thanks to PI speed and field-oriented current control technology. Additionally, it ensures system integrity by monitoring parameters such as terminal temperature, motor load, and detecting anomalies like overvoltage or under-voltage. The terminal facilitates EtherCAT communication for user PC control and provides a 16 LED diagnostic panel for warnings, status, and error messages. It offers direct servomotor connectivity via OCT, operates at 1 kHz speed controller frequency, and can supply a current of up to 4.5 A.
30 Day Warranty
Technical Specifications
  • Product Type: EtherCAT Servo Terminal
  • Manufacturer: BECKHOFF
  • Model: EL7211-9014
  • Designed For: AM8100 series synchronous servomotors
  • Control Type: Speed or torque oriented
  • Technology Support: One Cable Technology (OCT)
  • Control Technology: PI speed and field-oriented current control
  • Monitoring Parameters: Motor load, terminal temperature, overcurrent, under-voltage, overvoltage
  • Communication Support: EtherCAT
  • Diagnostic Panel: 16 LEDS
  • Channels: 1
  • Connections: 1 x motor brake output, 1 x servomotor output, 2 x end limit inputs, 1 x servomotor feedback input, 1 x STO input
  • Servomotor Connectivity: Direct via OCT
  • Rated Speed Controller Frequency: 1 kHz
  • Current Controller Frequency: 32 kHz
  • PWM Clock Frequency: 16 kHz
  • Weight: 95 grams
  • Operating Temperature Range: 0…+55 °C
  • Current Supply: Up to 4.5 A
