P image of EL7332

EL7332

by Beckhoff
$435.21 - $590.58
$435.21
$435.21 - $590.58
$435.21
The Beckhoff EL7332 EtherCAT terminal is tailored for the direct operation of two DC motors. With a 16-bit value preset speed from the automation device, this terminal ensures smooth performance and operation. It offers protection against short circuit and overload, while the LEDs provide quick local diagnostic support. Backed by a 24 V DC supply voltage, the EL7332 produces a maximum output current of 1 A per channel. It features effective cooling through the ZB8610 fan cartridge, distributed clocks, and travel distance control. This product weighs about 50g and has an IP 20 protection class. Its key approvals include CE and UL, and it adheres to the vibration standard EN 60068-2-6. The terminal has a PWM clock frequency of 32 kHz with a 180° phase shift, with a variable duty cycle between 0% to 100%. The shield busbars ZB85xx serve as optional accessories to enhance the EL7332's functionality.

Contact Us

Email: sales@servosupplier.com
Phone Number: 1-888-551-3082
International: 1-919-443-0207
Fax: 1-919-867-6204

Servo Supplier is not an authorized distributor. We sell new surplus and refurbished products. All warranties are with Servo Supplier and not the manufacturer.

Military Grade
Packaging

30 Day Warranty

Shipping Options

Payment Options

Technical Specifications

Manufacturer

Beckhoff

Product Type

EtherCAT Terminal

Series

EL7

Model

EL7332

Operation

Direct operation of two DC motors

Speed PReset

16-bit value

Output Stage Protection

Against short circuit and overload

Indication

LEDs

Input

End position per channel

Output

DC motor per channel

Supply Voltage

24 V DC

Output Current

1 A per channel

Performance Increase

Via ZB8610 fan cartridge

Features

Distributed clocks and travel distance control

Electrical Insulation

500 V

Weight

50 g

Protection Class

IP 20

Approvals

CE, UL

Vibration Conformance

EN 60068-2-6

PWM Clock Frequency

32 kHz

Duty Factor

0% to 100%

Add-on Accessory

ZB85xx shield busbar with mounting rail holder and shield busbar clamps.
