Servo Supplier is not an authorized distributor. We sell new surplus and refurbished products. All warranties are with Servo Supplier and not the manufacturer.
Breaking Energy
< 150 mJ/channel
Connection Technology
D-sub
Current Consumption E-bus
typ. 115 mA
Current Consumption X2
typ. 25 mA + load
Dimensions (w X H X D)
26.5 mm x 100 mm x 71 mm
Load Type
ohmic, inductive, lamp load
Max. Output Current
0.5 A per channel, individually short-circuit proof, ∑ 4 A
Number Of Outputs
16
Rated Load Voltage
24 V DC (-15%/+20%)
Reverse Voltage Protection
yes
Short-circuit Current
typ. < 2 A
Special Features
ideal for multi-pin connector valve terminals
Switching Times
typ. TON: 60 µs, typ. TOFF: 300 µs
Warranty
One-year
Weight
approx. 90 g
