EPP1322-0001

Name: EPP1322-0001
Brand: Beckhoff
Price: 1593.08 USD
Availability: InStock

by Beckhoff

$969.02 - $1,593.08

$969.02

$969.02 - $1,593.08

$969.02

The EPP1322-0001 from Beckhoff features a nominal voltage of 24 V DC and supports data transfer rates up to 100 Mbit/s. Part of the EPP EtherCAT P Box Modules, it weighs 165 g and offers protection ratings conforming to IP65/66/67. It includes one EtherCAT input and three EtherCAT P output ports, and provides 500 V electrical isolation at the input interface.

The module handles a maximum total current of 3 A per US and UP and consumes typically 100 mA, ensuring efficient power usage. It operates within –25 to +60 °C with a storage range from –40 to +85 °C. Its polyamide PA6 housing with polyurethane sealing affords robust shock and vibration resistance to EN 60068-2-6/27.

Contact Us

Email: sales@servosupplier.com

Phone Number: 1-888-551-3082

International: 1-919-443-0207

Fax: 1-919-867-6204

Servo Supplier is not an authorized distributor. We sell new surplus and refurbished products. All warranties are with Servo Supplier and not the manufacturer.

Military Grade
Packaging

30 Day Warranty

Shipping Options

Payment Options

Technical Specifications

Bus Interface

1 x M8 shielded socket; 1 x P‑coded M8 socket

Current Consumption

typ. 100 mA

Data Transfer Rate

100 Mbit/s

Distance Between Stations

100 m (100BASE‑TX)

EMC Conformance

EN 61000‑6‑2, EN 61000‑6‑4

EtherCAT Ports

1 IN, 3 EtherCAT P OUT

Max Total Current

3 A per US and UP

Nominal Voltage

24 V DC (‑15%/+20%)

Operating Temperature

‑25…+60°C

Power Supply Downstream Connector

1 x M8 female, 4‑pin, A‑coded

Power Supply Feed Connector

1 x M8 male, 4‑pin, A‑coded

Protocol

EtherCAT, EtherCAT P

Shock and Vibration Resistance

EN 60068‑2‑6, EN 60068‑2‑27

Storage Temperature

‑40…+85°C

Weight

Approx. 165 g
