The EPP1332-0001 is an EtherCAT P junction module from Beckhoff's EPP EtherCAT P Box Modules. It features an IP65/66/67 protection rating, a 24 V DC nominal voltage and supports 3 A per US and UP. Equipped with an M8 P-coded socket bus interface, it achieves 100 Mbit/s data rates. The compact design operates at -25...+60 °C, weighs 165 g, and offers integrated LED diagnostics.
Servo Supplier is not an authorized distributor. We sell new surplus and refurbished products. All warranties are with Servo Supplier and not the manufacturer.
Bus interface
M8 socket, P‑coded, shielded
Current consumption
100 mA (typ.)
Data rate
100 Mbit/s
EMC standard
EN 61000‑6‑2/6‑4
EtherCAT function
2‑port junction with US & UP refresh
EtherCAT P ports
1 IN, 3 OUT
Ingress protection
IP65/66/67
Max. current per supply (US & UP)
3 A
Nominal voltage
24 V DC (–15%/+20%)
Operating temp range
–25…+60°C
Power supply downstream
1 × M8 female, 4‑pin, a‑coded
Power supply feed
1 × M8 male, 4‑pin, a‑coded
Protocol
EtherCAT P
Storage temp range
–40…+85°C
Vibration/shock standard
EN 60068‑2‑6/2‑27
Weight
165 g (approx.)
