The Beckhoff EPP2316-0003 is an EtherCAT P Box in the EPP EtherCAT P Box Modules series, providing 8 inputs + 8 outputs at 24 V DC, 0.5 A/channel short-circuit-proof. It features 10 µs filters, spring-loaded connectors, 2×M8 sockets, IP20 protection and weighs 165 g.
Servo Supplier is not an authorized distributor. We sell new surplus and refurbished products. All warranties are with Servo Supplier and not the manufacturer.
Bus Interface
2×M8 socket, P‑coded, shielded
Channels
8 inputs + 8 outputs
Connections
Spring‑loaded connector
Electrical Isolation
500 V
Input Current
6 mA (EN 61131‑2 Type 3)
Input Filter
10 µs
Load Types
Ohmic, inductive, lamp
Max Output Current
0.5 A/channel, short‑circuit proof
Protocol
EtherCAT
Rated Load Voltage
24 V DC (-15%/+20%)
Sensor Supply
From control voltage, max. 0.5 A, short‑circuit proof
Signal Voltage Range
-3…+5 V
Standards
EN 61131‑2 Type 1/3
Supply Voltage
11…30 V DC
Switch‑off Time
50 µs (typ.)
Switch‑on Time
25 µs (typ.)
Weight
165 g (approx.)
