The EPP2624-0002 is a four channel relay output EtherCAT P Box module by Beckhoff, part of the EPP EtherCAT P Box Modules series. It features 4 make contact outputs with 0.5 A AC/2 A DC ohmic switching current at 25 V AC/30 V DC, powered via 2 × P-coded M8 sockets and delivering signals through M12 x 1, 5-pin, a-coded connectors. Rated IP65/66/67 for harsh industrial environments, it consumes typ. 100 mA from the 24 V DC supply.
Servo Supplier is not an authorized distributor. We sell new surplus and refurbished products. All warranties are with Servo Supplier and not the manufacturer.
Bus Interface
2 x M8 socket, P-coded, shielded
Current Consumption (u S)
typ. 100 mA
Load Type
ohmic, inductive, lamp load
Minimum Permitted Load
10 µA at 10 mV DC
Nominal Output Voltage
24 V DC (-15%/+20%)
Number Of Outputs
4 x make contacts
Ohmic Switching Current
0.5 A AC/2 A DC
Operating Cycles (electrical)
2 x 10^5 (1 A/30 V DC)
Operating Cycles (mechanical)
1 x 10^8
Operating/storage Temperature
-25…+60°C/-40…+85°C
Output Connections
M12 x 1, 5-pin, a-coded
Protocol
EtherCAT
Rated Load Voltage
25 V AC/30 V DC
Special Features
potential-free switching
Weight
approx. 165 g
