The ES2024 is a 2-wire connection digital output terminal by Beckhoff, part of the ES EtherCAT Terminals series. It features 4 outputs at 24 V DC nominal, each delivering 2.0 A with short‑circuit proof design. Supporting ohmic, inductive, and lamp loads, it offers fast switching (TON 40 µs, TOFF 200 µs) and meets IP20 protection and EN 61000‑6‑2/‑6‑4 EMC standards.
Servo Supplier is not an authorized distributor. We sell new surplus and refurbished products. All warranties are with Servo Supplier and not the manufacturer.
Bit Width In Process Image
4 outputs
Breaking Energy
< 1.7 J/channel
Connection Technology
2-wire
Current Consumption E-bus
Typical 120 mA
Current Consumption Power Contacts
Typical 13 mA + load
Emc Immunity/emission
Conforms to EN 61000-6-2/EN 61000-6-4
Ex Marking
II 3 G Ex nA IIC T4 Gc
Load Type
Ohmic, inductive, lamp load
Nominal Voltage
24 V DC (-15%/+20%)
Number Of Outputs
4
Operating/storage Temperature
-25…+60 °C/-40…+85 °C
Output Current
2.0 A (short-circuit proof) per channel
Protection Rating/installation Position
IP20/any
Switching Times
Typical TON: 40 µs, TOFF: 200 µs
Vibration/shock Resistance
Conforms to EN 60068-2-6/EN 60068-2-27
