The Beckhoff ES4002 is a robust analog output terminal from the ES EtherCAT Terminals series, delivering 2 outputs at 12-bit resolution (0–10 V) and with short-circuit proof load (>5 kΩ). It runs on 24 V DC, offers distributed clock precision <1 µs, features IP20 protection and pluggable wiring, and operates from −25 °C to +60 °C.
Servo Supplier is not an authorized distributor. We sell new surplus and refurbished products. All warranties are with Servo Supplier and not the manufacturer.
Analog outputs
2×16 bit
Conversion time
~150 μs
Current consumption (e-bus)
140 mA typ.
Current consumption (power contacts)
40 mA typ.
Distributed clock precision
<1 μs
Distributed clocks
supported
Operating temperature
-25 to +60 °C
Output error
<0.1% FS
Output load
>5 kΩ, short-circuit proof
Output resolution
12 bit
Output signal voltage
0 to 10 V
Power supply
24 V DC (via power contacts)
User synchronization
supported
Watchdog timer
optional with user-defined ramp
Weight
approx. 60 g
