ES4104

The Beckhoff ES4104 terminal within the ES EtherCAT Terminals series by manufacturer delivers precise analog output via its four high-resolution channels, each offering Resolution capability for demanding industrial control applications. Engineered to produce accurate signals with an Output error margin of less than 0.1% relative to the end value, the ES4104 supports a maximum Output rate of 4 ksps and an operational Bandwidth of 50 Hz. Distributed clock synchronization ensures timing coherence across the EtherCAT network, achieving a precision of Distributed clock precision for real-time performance. Compact yet robust, it draws power directly from the E-bus, minimizing cabling complexity while maximizing system uptime and reliability. The module’s combination of high fidelity output and deterministic timing positions it as a core component in modern automation architectures.

The ES4104’s technical specifications define its exceptional capability: a Bit width in the process image of 4 x 16 bit AO output, a signed Resolution of 16 bit per channel, and inherent support for Distributed clocks. Electrical isolation of Electrical isolation separates the E-bus from the signal voltage, ensuring both operator safety and signal integrity. The terminal’s load-driving capacity exceeds Load, remaining short-circuit proof under worst-case conditions. With typical Current consumption E-bus of 190 mA and a steady Power Consumption of 10 W via the E-bus, the ES4104 balances energy efficiency with high performance. Physical package dimensions of Physical Dimensions and a mass of Weight streamline integration in densely populated control cabinets.

Operational features emphasize reliability and real-time responsiveness. The ES4104 accommodates synchronized data exchange through a built-in Interface port and offers resistance to overcurrent and short circuits on its output channels. Its distributed clock architecture under 1 µs ensures tight phase alignment, critical for multi-axis motion control and process synchronization. The module supports an extended Output rate of up to 4 ksps per channel, coupled with a Bandwidth of 50 Hz to satisfy both slow analog setpoints and dynamic control loops. Its compact form factor and robust construction enable stable operation under continuous load conditions.

System integration is optimized for EtherCAT-based automation platforms, with seamless compatibility within the ES EtherCAT Terminals ecosystem. The ES4104 links directly to Beckhoff control processors over the E-bus, while the optional RS-232 Interface supports advanced configuration and diagnostics. This terminal is ideal for applications in industrial automation, process control, machine building, and high-precision measurement systems requiring synchronized analog outputs.
