S image of ES7031

ES7031

by Beckhoff
$14,765.30 - $16,241.83
$14,765.30
$14,765.30 - $16,241.83
$14,765.30

In Stock, Ships 1 - 3 Days

The ES7031 terminal from Beckhoff’s ES EtherCAT Terminals series supports direct connection of 2-phase stepper motors. It features 64-fold microstepping, up to 8000 full steps/s frequency, a maximum output current of 1.5 A, and two end-position inputs. The module operates at 0–55 °C, is CE and UL certified, and meets EN 61000-6-2/6-4 EMC standards. It uses 24 V DC supply voltage and conforms to EN 60068-2-6/-27 vibration and shock resistance.

Contact Us

Email: sales@servosupplier.com
Phone Number: 1-888-551-3082
International: 1-919-443-0207
Fax: 1-919-867-6204

Servo Supplier is not an authorized distributor. We sell new surplus and refurbished products. All warranties are with Servo Supplier and not the manufacturer.

Military Grade
Packaging

30 Day Warranty

Shipping Options

Payment Options

Technical Specifications

Approvals/markings

CE, UL

Connection Method

direct motor connection

Emc Immunity/emission

conforms to EN 61000-6-2/EN 61000-6-4

Load Type

2-phase stepper motor (uni-/bipolar)

Number Of Channels

1

Number Of Inputs

2 x end position

Number Of Outputs

1 x stepper motor

Operating Temperature

0…55°C

Output Current

max. 1.5 A

Step Frequency

configurable up to 8000 full steps/s

Step Pattern

64-fold micro stepping

Supply Voltage Electronics

24 V DC (via power contacts)

Vibration/shock Resistance

conforms to EN 60068-2-6/EN 60068-2-27
