ES9410
by Beckhoff
The Beckhoff ES9410 terminal is part of the ES EtherCAT Terminals series by Beckhoff. It accepts an input voltage of 24 V DC (-15%/+20%), provides a regulated 5 V DC output for the E-bus and up to 2 A current supply, and features short-circuit proof protection. This compact module, weighing approximately 65 g, serves as a power refresh point in EtherCAT networks, guaranteeing stable voltage distribution across connected I/O terminals and preventing bus voltage decay under heavy load.
In terms of detailed technical specifications, the ES9410 draws a typical input current of 70 mA + (E-bus/4) and supports power contacts rated at max. 24 V DC / max. 10 A. It offers electrical isolation up to 500 V between the E-bus and field potential, ensuring safe separation of control and field circuits. The module includes diagnostic capabilities in the process image and LED indicators for real-time status monitoring. Certified under CE, CCC, UL, ATEX, IECEx, DNV GL, this terminal adheres to rigorous industry safety and performance standards. Its standard EL supply feature simplifies integration into existing EtherCAT infrastructures.
The ES9410 operates reliably over a wide environmental range, from –25 … +55 °C (operating) and can be stored between –25 … +85 °C, tolerating up to 95% relative humidity (non-condensing). Its lightweight design and compact dimensions enhance installation flexibility in space-constrained control cabinets. By decentralizing power insertion points, the module improves system design efficiency and reduces cabling complexity. With robust approvals and proven durability, the ES9410 delivers reliable power management and diagnostics in demanding industrial automation applications, boosting uptime and simplifying maintenance in complex EtherCAT networks.
