FC7501-0000

Name: FC7501-0000
Brand: Beckhoff
Price: 2878.27 USD
Availability: InStock

by Beckhoff

$914.65 - $2,878.27

$914.65

$914.65 - $2,878.27

$914.65

In Stock, Ships 1 - 3 Days

The Beckhoff FC7501-0000 card from the FC Lightbus Cards series provides reliable synchronous communication on the SERCOS II fieldbus via PCI, offering data transfer rates of 2, 4, 8, and 16 Mbaud. It features 1 fieldbus channel with 2 FSMA connectors (IEC 874-2), hardware diagnostics via 1 LED per channel, and supports up to 254 devices including axes and I/O modules. With a TwinCAT I/O driver and precise synchronization between TwinCAT and SERCOS, multiple cards can be linked via ribbon cable. Housed in a compact 95 mm x 120 mm form factor, it operates from 0 to +55 °C, ensuring robust performance in industrial automation environments.

Contact Us

Email: sales@servosupplier.com

Phone Number: 1-888-551-3082

International: 1-919-443-0207

Fax: 1-919-867-6204

Servo Supplier is not an authorized distributor. We sell new surplus and refurbished products. All warranties are with Servo Supplier and not the manufacturer.

Military Grade
Packaging

30 Day Warranty

Shipping Options

Payment Options

Technical Specifications

Bus Interface

2 x connector FSMA according to IEC 874-2

Data Transfer Rates

2, 4, 8, 16 Mbaud

Dimensions

approx. 95 mm x 120 mm

Driver

TwinCAT I/O and higher levels

Exact Synchronization

between TwinCAT and SERCOS

Fieldbus

SERCOS II

Hardware Diagnostics

1 LED per channel

I/o Configuration

any assignment and length of the I/O data

Number Of Fieldbus Channels

Operating Temperature

0…+55°C

Pc Interface

PCI

Support

up to 254 devices (axes, I/O modules)

Synchronization

synchronization of several cards via ribbon cable

Synchronous Communication

process data synchronization
