FS1W075P26

The Sanyo Denki FS1W075P26 is a compact, high-performance member of the F SANMOTION Servo Amplifiers series, designed specifically for precision motion control in industrial environments. Manufactured by Sanyo Denki, this single-phase amplifier delivers a Holding Torque: 0.13 Nm (18.41 oz-in) at an Operating Current: 0.75 A/phase and Rated Current: 0.75 A/phase. It is configured to match motors with a Motor Size: 42 mm sq. (1.65 inch sq.) and a Motor Length: 34 mm (1.34 inch), providing exceptional power density in a minimal footprint. The unit accepts a Power Supply Voltage: AC100V / AC200V input at 50/60 Hz, ensuring compatibility with a wide range of industrial automation power systems.

Technical capabilities of the FS1W075P26 are defined by its precise electrical and mechanical design. The amplifier supports a Basic Step Angle: 0.72 degrees, offering fine positioning resolution for demanding applications. It is rated to withstand an Allowable Radial Load: 35 N (8.75 lbs) and an Allowable Thrust Load: 10 N (2.25 lbs) on its shaft interface, ensuring robust operation under external forces. With a minimal Rotor Inertia: 0.16 oz-in² and a lightweight Motor Mass: 0.23 kg (0.51 lbs), the system accelerates and decelerates rapidly, minimizing settling times. Seamless integration with corresponding motor models – 103M5505-7011 for double-shaft and 103M5505-7041 for single-shaft – is facilitated by dedicated ordering models FSM551D and FSM551S.

Operational features emphasize reliability and ease of use in industrial settings. The FS1W075P26 supports closed-loop control for speed and position, enabling highly stable four-quadrant operation and smooth performance even at low speeds. Engineers benefit from live connecting points for quick status checks during installation and maintenance, reducing downtime. Fast commissioning and diagnostics streamline setup, while the integrated protective earth terminal ensures safe grounding of the motor. The amplifier’s compact form factor and standardized connectors simplify cable routing in confined control cabinets.

This servo amplifier integrates seamlessly into single-axis and multi-axis drive systems, making it ideal for CNC machinery, pick-and-place robots, and precision assembly lines. Its compatibility with the complete Sanyo Denki SANMOTION ecosystem allows for advanced motion profiles and coordinated control across multiple axes. By leveraging the FS1W075P26’s robust specifications and simplified connectivity, system designers can optimize throughput, reduce maintenance intervals, and enhance overall equipment effectiveness in demanding industrial automation applications.
