S image of FVCA01.1-1K50-3P4-MDA-LP-P002-01V01

FVCA01.1-1K50-3P4-MDA-LP-P002-01V01

by Bosch Rexroth Indramat
$1,751.50 - $1,751.50
$1,751.50
$1,751.50 - $1,751.50
$1,751.50

In Stock, Ships 1 - 3 Days

The Bosch Rexroth Indramat FVCA01.1-1K50-3P4-MDA-LP-P002-01V01 is a frequency converter with a 1.5-kilowatt output rating, 4.0 Amp output current rating, and a 5.1 Amp input current rating. This model supports an apparent power rating of 2.6 kVA, and incorporates features including an EMC Class C3 filter, LCD display, and Modbus communication interface. Housed within an IP 20 rated enclosure designed for control cabinet and wall mounting, this frequency converter employs forced air cooling and operates on a 400-Volt AC (3-phase, 50 to 60 Hertz) mains connection. It can function at temperatures ranging from -10 to 40 degrees Celsius, and elevations up to 4000 meters (with certain output derating conditions). The FVCA01.1-1K50-3P4-MDA-LP-P002-01V01 also supports protection mechanisms against motor overheat, input/output phase failure, and under-voltage, and can be fitted with accessories like a brake chopper, brake resistor, Profibus adapter, and communication cable. Its weight is 2.7 kilograms and measures 275 x 125 x 127 millimeters.

Contact Us

Email: sales@servosupplier.com
Phone Number: 1-888-551-3082
International: 1-919-443-0207
Fax: 1-919-867-6204

Servo Supplier is not an authorized distributor. We sell new surplus and refurbished products. All warranties are with Servo Supplier and not the manufacturer.

Military Grade
Packaging

30 Day Warranty

Shipping Options

Payment Options

Technical Specifications

Manufacturer

Bosch Rexroth Indramat

Product Type

Frequency Converter

Product Code

FVCA01.1-1K50-3P4-MDA-LP-P002-01V01

Output Rating

1.5 kilowatts

Output Current Rating

4.0 Amps

Input Current Rating

5.1 Amps

Apparent Power Rating

2.6 kVA

Integrated Features

Modbus communication interface, LCD display, EMC filter (Class C3)

Firmware Version

01

Firmware Release Status

01

Enclosure

IP 20 rated, designed for control cabinet or wall mounting

Cooling Method

Forced air cooling

Mains Connection Voltage

400 Volts AC (3-phase, 50 to 60 Hertz)

Temperature Range

-10 to 40 degrees Celsius (output derates from 40 to 50 degrees Celsius, max 10% at 50 degrees Celsius)

Altitude

Installation up to 1000m without output derating (above this, output derates by 1% per 100m increase)

Relative Humidity

Should be less than 90%

Pollution Degree

2 (as per EN 50178)

Accessories

Brake chopper, brake resistor, Profibus adapter, control cabinet communication cable

Protection Features

Motor overheat, input phase failure, output phase failure, under-voltage

Weight

2.7 kilograms

Dimensions

275x125x127 millimeters
