HA035-017BC001
The Sanyo Denki HA035-017BC001 from the High Accuracy Absolute Encoders series is a batteryless Absolute Encoder with 23-bit resolution and 147 m/s² vibration resistance, delivering precise, maintenance-free operation. Featuring a 1/17 gear ratio, it provides an output torque of 35 Nm (peak 70 Nm), while operating at ≥85% efficiency. This compact unit measures 51 mm in length, has an outer diameter of 90 mm, and weighs 1.3 kg. It supports a rated output speed of 117 rpm, an allowable input speed of 2000 rpm, allowable radial and axial loads of 1800 N and 900 N, and typical backlash of ≤41 arcmin, making it ideal for demanding industrial automation applications.
