P image of HCS01.1E-W0018-A-03-B-ET-EC-PB-NN-NN-FW

HCS01.1E-W0018-A-03-B-ET-EC-PB-NN-NN-FW

by Bosch Rexroth Indramat
$2,948.60 - $2,948.60
$2,948.60
$2,948.60 - $2,948.60
$2,948.60

Available, Shipping Varies

The HCS01.1E-W0018-A-03-B-ET-EC-PB-NN-NN-FW industrial drive controller, fabricated by Bosch Rexroth Indramat, is designed for three-phase AC systems, with an input voltage range of 200 to 500 Volts AC. It has a maximum output current of 18 Amperes and incorporates a Multi-Ethernet communication interface in addition to a multi-encoder interface. An IP20 rated housing protects the controller which is built for vertical installation and a back-side mounting orientation is recommended. The device measures 268mm in height, 70mm in width, and 196mm in depth, weighing 2.1kg. Its operation temperature extends from 0 to 40 degrees Celsius (with reduced data from 0 to 55 degrees Celsius) and it comes equipped with a basic control section and a Profibus module. Firmware for this controller needs to be separately ordered and it should only be operated by trained personnel.

Contact Us

Email: sales@servosupplier.com
Phone Number: 1-888-551-3082
International: 1-919-443-0207
Fax: 1-919-867-6204

Servo Supplier is not an authorized distributor. We sell new surplus and refurbished products. All warranties are with Servo Supplier and not the manufacturer.

Military Grade
Packaging

30 Day Warranty

Shipping Options

Payment Options

Technical Specifications

Manufacturer

Bosch Rexroth Indramat

Product

HCS01.1E-W0018-A-03-B-ET-EC-PB-NN-NN-FW

Max Current Output

18 Amps

Voltage Range

200-500 Volts AC

Phasing

Three-phase AC

Protection Class

IP20

Mounting Style

Vertical

Dimensions

268mm x 70mm x 196mm

Weight

2.1 kilograms

Insulation Resistance

10 megaohms at 500 Volts DC

Capacitance Against Housing

2 x 100 nanofarads

Operating Temperature

0 to 40 degrees Celsius (rated data)

Reduced Nominal Data Temperature

0 to 55 degrees Celsius

Cooling

Forced Air

Minimum Spacing (Top and Bottom)

90 millimeters

Horizontal Spacing

Not required

Basic Control Section

Included

Communication Interface

Multi-Ethernet

Multi-Encoder Interface

Included

Profibus Module

Included

Installation Orientation

Back-side mounting

Control Panel

Standard (with display and keypad)

Firmware

Ordered separately
