HCT02.1E-W0020-A-03-B-L8-2N-NN-NN-NN-FW

Original price $16,672.50 - Original price $16,672.50
Original price
$16,672.50
$16,672.50 - $16,672.50
Current price $16,672.50
In Stock, Ships 3 - 5 Days
Request a quote
Produced by Bosch Rexroth Indramat, the HCT02.1E-W0020-A-03-B-L8-2N-NN-NN-NN-FW is a part of their HCT02 series multi-axis converter drive controllers. This controller caters to three-phase AC asynchronous or synchronous motors, including one primary and two secondary axes. With protection category IP 20, it satisfies UL recognition and needs to be vertically installed in a pre-conditioned control cabinet. Operating conditions stipulate 0 to 40-degree temperature, 95% humidity sans condensation, and up to 1000 meters of mounting elevation. The UL rated inputs include a 42000A rms short circuit current, 3 x AC 200-500 voltage, 44.0A current, and a 3 x AC 0-500V output voltage. Additional specs encompass a 20kW power rating, feeding power supply, basic construction, and an embedded PC LX 800 for master communication. Firmware availability is separate. Accessories include screws, labels, a CompactFlash memory card and LED displays for diagnostics. It also includes 16 digital outputs, 32 digital inputs and 4 probes. It employes a forced-ventilation cooling method.
30 Day Warranty
Technical Specifications
  • Manufacturer: Bosch Rexroth Indramat
  • Product Series: HCT02
  • Product Model: HCT02.1E-W0020-A-03-B-L8-2N-NN-NN-NN-FW
  • Axis Operation: One main and two secondary
  • Motor Compatibility: Three-phase AC asynchronous or synchronous motors
  • Protection Category: IP 20
  • Mounting Position: Vertical in control cabinet
  • Operating Temperature: 0 to 40 degrees
  • Relative Humidity: 95% without condensation
  • Installation Altitude: 1000 meters
  • Rated Input Voltage: 3 x AC 200-500
  • Rated Input Current: 44.0A
  • Output Voltage: 3 x AC 0-500V
  • Power Supply: Feeding
  • Rated Power: 20kW
  • Construction: Basic
  • Master Communication: Embedded PC, LX 800
  • Commisioning and Diagnostic Display: LED
  • Digital Outputs: 16
  • Digital Inputs: 32
  • Probes: 4
  • Relay Contacts: 1
  • Cooling Method: Forced-ventilated
