S image of HDD02.2-W016N-HD32-01-FW

HDD02.2-W016N-HD32-01-FW

by Bosch Rexroth Indramat
$13,640.92 - $13,640.92
$13,640.92
$13,640.92 - $13,640.92
$13,640.92

In Stock, Ships 1 - 3 Days

The HDD02.2-W016N-HD32-01-FW Drive Controller, created by Bosch Rexroth Indramat, is a highly functional device with a 16A current rating. The controller boasts two grounding connections to its supply module; one on the back wall and mounting rails, and another via the grounding clip positioned in front. It requires specific motor power cables from the same manufacturer for connection, with an overall maximum length of 75m. It also includes an XS1 shield attachment connector for mounting the motor cable shield. During operation, a cooling system is necessary to prevent water condensation on the controller. The device excels in multiple or single-axis control applications. The unit and firmware type plates are located at the controller's top, with firmware available as a separate subitem. The device should be stored and transported in a shock and dust-free environment, using shock-absorbing supports if necessary. Ensure guards and covers are properly installed to avoid contact with live parts.

Contact Us

Email: sales@servosupplier.com
Phone Number: 1-888-551-3082
International: 1-919-443-0207
Fax: 1-919-867-6204

Servo Supplier is not an authorized distributor. We sell new surplus and refurbished products. All warranties are with Servo Supplier and not the manufacturer.

Military Grade
Packaging

30 Day Warranty

Shipping Options

Payment Options

Technical Specifications

Manufacturer

Bosch Rexroth Indramat

Product Code

HDD02.2-W016N-HD32-01-FW

Current Rating

16A

Ground Connections

Two, one on mounting rails and back wall, one through grounding clip

Motor and Unit Connection

Requires motor power cables from same manufacturer

Cable Length

Maximum 75m

Shield Attachment Connector

XS1

Cooling System Requirement

Yes

Type Plates Location

Top of the controller

Firmware Availability

Separate subitem from manufacturer

Transportation Requirement

Transported using appropriate transportation equipment, shock-absorbing supports if necessary

Storage Requirement

Dry, dust-free place

Packaging for Modules

Conductive

Guards and Covers

Must be installed and not in contact with any live part
