HDS02.1-W040N-HS33-01-FW
The HDS02.1-W040N-HS33-01-FW belongs to the HDS Drive Controllers series from Bosch Rexroth Indramat and is used in multi-axis motion platforms for industrial automation. Within a DIAX modular rack, this unit acts as a closed-loop power stage that receives motion commands from a higher-level CNC or PLC and regulates the connected servo motor for synchronized positioning and speed control on production machinery. It converts control commands into regulated electrical output so the axis can follow programmed motion with repeatable response. This type of controller is commonly applied where several machine axes must accelerate, hold speed, and stop in a coordinated sequence. Closed-loop regulation helps the drive maintain stable motion when load conditions change during normal machine cycles.
The controller exchanges setpoints and feedback through the SERCOS fiber-optic bus, so deterministic telegrams carry velocity, torque, and status information at high speed. A continuous output capability of 40 A allows it to drive medium-frame servo axes without current derating under nominal load. Thermal regulation is handled by a built-in air blower that directs cabinet air across the heat sink, so no separate external fan assembly is required for normal cooling. The blower supports continuous heat removal from the power section during sustained axis duty in enclosed cabinets. The unit is part of the DIAX04 controller family, which uses a common connector layout across compatible rack components. This arrangement supports consistent communication timing between the controller and the higher-level motion control.
The product is part of Line 02 in the series. The drive is Version 1, which identifies its product revision. Its functional category is a HDS Drive Controller, so it is intended for servo axes rather than spindle drives. These identifiers help distinguish the controller within a DIAX rack that contains multiple drive modules.
