series image of HDS03.1-W100N-HA01-01-FW

HDS03.1-W100N-HA01-01-FW

by Bosch Rexroth Indramat
Request a quote
The Bosch Rexroth Indramat HDS03.1-W100N-HA01-01-FW is part of the HDS series and serves as a dynamic, modular drive controller suited for commercial machinery. It is designed for installation in a secure control cabinet and produces a rated current of 100 Amps. This unit uses a single supply and features plug-in, command communication, and software modules for tailored configurations. It also features a self-regulated cooling system set at 40°C, with a built-in blower for internal heat dissipation. The controller can handle maximum motor and feedback cable lengths of 75 meters and provides error messaging through its SERCOS interface. Its power cables should be shielded and contain a conductor, adhering to DIN VDE 0160 standards. This unit is part of the DIAX04 controller family and functions as both a servo drive and the main drive, offering rapid response capabilities.
30 Day Warranty
Technical Specifications
  • Manufacturer: Bosch Rexroth Indramat
  • Product: HDS03.1-W100N-HA01-01-FW Drive Controller
  • Series: HDS
  • Modular Structure: Yes
  • Rate Current: 100 Amps
  • Cooling System: Self-adjusting temperature at 40 degrees Celsius
  • Maximum Motor Cable Length: 75 meters
  • Maximum Feedback Cable Length: 75 meters
  • Controller Family: DIAX04
  • Peak Current: 100 amps
  • Power Loss: 280 Watts
  • Weight: 11 kilograms
  • Status Display: Yes
  • Blower Unit: Built-in
  • Command Communication Interface: Analog
  • Power Voltage Source: HVR or HVE supply modules
  • Application: Can be used as a servo drive and the main drive
  • Cable Type: Motor Power Cables with Protective Shield and Conductor
  • Testing Standards: Insulation and High Voltage tests as per DIN VDE 0160 standards.
