HMD01.1N-W0036-A-07-NNNN

Original price $2,247.00 - Original price $2,247.00
Original price
$2,247.00
$2,247.00 - $2,247.00
Current price $2,247.00
In Stock, Ships Today
Request a quote
The HMD01.1N-W0036-A-07-NNNN power section by Bosch Rexroth Indramat is a module found in their HMD product group. This unit, part of the IndraDrive M series, should be in a location protected from foreign objects and liquids, and is air-cooled by a blower during operation. The device operates under a potential for high leakage current, elevated housing voltage, and may experience unpredictable movements due to defective components or improper cabling. Its prominent features include a nominal Y-capacitance of 2 * 68 nF, a continuous output current of 13A at 8kHz and 20A at 4kHz, a maximum ambient temperature of 55°C, and a DC bus voltage range of 254VDC to 750VDC. The section requires a specific clearance, uses shielded motor power cables, and includes a connector for monitoring the motor's temperature. The connection cables' cross-sectional area is between 0.5mm2 and 1.5mm2. Lastly, it has a switching frequency of 0.5Hz and a 50ms load time constant.
30 Day Warranty
Technical Specifications
  • Manufacturer: Bosch Rexroth Indramat
  • Product Type: Power Section
  • Product Code: HMD01.1N-W0036-A-07-NNNN
  • Product Group: HMD
  • Fitted to: IndraDrive M series Drive Controller
  • Predicted Experience: High Leakage Current and High Housing Voltage possible
  • Cooling Method: Air Circulation via Blower
  • Nominal Y-Capacitance: 2 * 68 nF
  • Continuous output current: 13A at 8kHz and 20A at 4kHz
  • Maximum Ambient Temperature: 55°C
  • Minimum Clearance Required: 80mm top, 100mm bottom
  • Connection Method: Shielded Motor Power Cables
  • DC Bus Voltage: 254VDC to 750VDC
  • Required Distance From Magnetic Components: At least 400mm
  • Connector Type: X6
  • Cable Cross-sectional Area: 0.5mm2 min, 1.5mm2 max
  • Switching Frequency: 0.5Hz
  • Load Time Constant: 50ms
