HMS01.1N-W0054-A-07-NNNN

Request a quote
The Bosch Rexroth Indramat HMS01.1N-W0054-A-07-NNNN is a power section designed for integration within an IndraDyn M drive controller. The module requires connection to an external 24VDC power supply and facilitates the addition of a HAS05 adapter for the DC bus connection, functioning as an RS232/485 converter. To ensure efficient air circulation, the unit should be mounted with greater clearance at the bottom than the top. The device provides external branch circuit protection and utilizes the X1 connector for connection to a bus module. It possesses control voltage ranging between 0 and 24V, with the A1, A2, and A3 terminals protected against short circuits with the ground. An external 24V supply voltage can be switched to the output through an integrated contact element, allowing control over a motor holding brake. The module consumes 10W of power without the motor brake and control unit.
30 Day Warranty
Technical Specifications
  • Manufacturer: Bosch Rexroth Indramat
  • Product Type: Power Section
  • Power Supply Requirement: External 24VDC
  • Required Power Supply Units: HMV or similar
  • Clearance Requirement: More at bottom than top
  • Adaptor Compatibility: HAS05 adaptor
  • Included Connection: HAS02 shield connection
  • Branch Circuit Protection: Required
  • X1 Connector Compatibility: Bus module connection using flat ribbon cable
  • Control Voltage: 0 - 24V
  • Terminal Features: Short circuit protection
  • Screw Tightening Torque: 1.5Nm - 1.8Nm
  • Cable Cross-Sectional Area: 1.5mm2 - 16mm2
  • Power Connection: A1, A2, and A3 terminals to U1, V1, and W1 terminals at motor
  • Nominal Bus Voltage Rating: 700VDC
  • External Voltage Switching: Possible via integrated contact element
  • X6 Connector Function: Control over motor holding brake
  • Power Consumption: 10W without motor brake and control unit.
