S image of HMV01.1E-W0030-A-07-FCN1

HMV01.1E-W0030-A-07-FCN1

by Bosch Rexroth Indramat
$9,076.40 - $9,076.40
$9,076.40
$9,076.40 - $9,076.40
$9,076.40

In Stock, Ships Fast

The HMV01.1E-W0030-A-07-FCN1 is a power supply unit manufactured by Bosch Rexroth Indramat for use with drive controllers of the HMV series. The unit should not be altered or operated if damaged and any modifications must occur while it is not powered. It comes with an identification plate indicating its serial number, hardware index, part number, and device type. The device is CSA Certified, UL Listed and weighs 13.5kg. The system optimally functions as a feeder power supply and is capable of providing the rated input current required by the drive components. It includes three connection terminals and can support multiple drive controllers. It operates with a cooling system powered by internal air circulation. The power supply unit should not be connected in reverse polarity to prevent damage. Additional grounding and connection specifications, including the use of M6 x 28 screws, should be carefully observed during installation.

Contact Us

Email: sales@servosupplier.com
Phone Number: 1-888-551-3082
International: 1-919-443-0207
Fax: 1-919-867-6204

Servo Supplier is not an authorized distributor. We sell new surplus and refurbished products. All warranties are with Servo Supplier and not the manufacturer.

Military Grade
Packaging

30 Day Warranty

Shipping Options

Payment Options

Technical Specifications

Manufacturer

Bosch Rexroth Indramat

Product Series

HMV series

Status Indicator

X31 connector

Weight

13.5kg

Operating Mechanism

Feeder power supply

Connection Terminals

Three (X31, X32, X33)

Cooling Method

Internal air circulation

DC Bus Connection Usage

For connecting multiple or single drive controllers

Polarity Warning

Do not reverse the DC bus connection terminals

Joint Bar Location

Front

Equipment Grounding Connection

Minimum of 10mm2 or AWG 8

Equipment Grounding Connector

Connected with M6 x 28 screws

Tightening Torque of Screws

6Nm

Certification

CSA Certified and UL Listed

Fitting Warning

No removal or fitting of components when power is on

Additional Features

Equipped with choke and type-plate having information like serial number, hardware index, part number, and device type.
