HMV01.1E-W0075-A-07-FCN1

Original price $10,726.00 - Original price $10,726.00
Original price
$10,726.00
$10,726.00 - $10,726.00
Current price $10,726.00
Available, Shipping Varies
The Bosch Rexroth Indramat HMV01.1E-W0075-A-07-FCN1 is a high-quality supply module designed for powering HMS inverter systems. In addition to generating DC bus voltage, this model also functions as a rectifier. It includes a built-in brake resistor that dissipates heat generated during rapid deceleration of high-speed motors. This process, known as dynamic braking, helps maintain an optimal motor temperature, even with continuous use. To prevent overheating, the model employs a blower fan for efficient heat dissipation. Adhering to EN standards, the device integrates a three-phase supply module for standard operations running between 380 V and 480 V, and delivers an output of 435 to 710 VDC. The HMV01.1E-W0075-A-07-FCN1 weighs approximately 22 kg and measures 440 mm in height, 250 mm in width, and 262 mm in depth. The device operates efficiently within a temperature range of 0 - 40ᵒC.
30 Day Warranty
Technical Specifications
  • Manufacturer: Bosch Rexroth Indramat
  • Product Model: HMV01.1E-W0075-A-07-FCN1
  • Product Type: Supply Module
  • Use: Powering HMS Inverter Systems, Rectifier
  • Additional Features: Inbuilt Brake Resistor, Forced Ventilation
  • Compliance Standards: EN Standards
  • Short Circuit Current Rating: 42000 A
  • Supply Type: Three-Phase
  • Operating Voltage: 380-480 V
  • Output Voltage: 435-710 VDC
  • Input Current: 128 A
  • Output Current: 173 A
  • Weight: 22 kg
  • Dimensions: 440 mm (Height), 250 mm (Width), 262 mm (Depth)
  • Sound Levels: Up to 75 db(A)
  • Input Frequency: 50-60 Hz
  • Operating Temperature Range: 0-40 ᵒC
