HMV02.1R-W0015-A-07-FNN2
The HMV02.1R-W0015-A-07-FNN2 is an HMV power supply module created by Bosch Rexroth Indramat, primarily designed for use with power sections HMD and HMS. The module provides power to corresponding power sections and operates by using a regenerative mechanism to efficiently transfer energy back to the grid, eliminating excess heat and additional costs in the process. The cooling mode is internal air-cooling with an integrated blower and the rated output stands at 15 kW. The module has an approximate weight of 9.5 kg and is capable of operating within an ambient temperature of up to 40 degrees C or 55 degrees C at reduced specifications. The operational frequency ranges from 50 to 60 Hertz, with a tolerance of ±2. The 3-phase input voltage falls within 380 to 480 VAC with a tolerance of ±10%, and the required wire size, as per EN 60204-1 standards, is 6 mm2. The equipment features screw mains connection ports and a 24V supply terminal, both possessing their respective minimum and maximum tightening torque values. Its protection category is classified as IP 20.
