S image of HNL01.1E-0200-N0125-A-480-NNNN

HNL01.1E-0200-N0125-A-480-NNNN

by Bosch Rexroth Indramat
$1,620.66 - $4,003.38
$1,620.66
$1,620.66 - $4,003.38
$1,620.66
The Bosch Rexroth Indramat HNL01.1E-0200-N0125-A-480-NNNN mains choke is designed to work with the HCS01, HCS02 and HCS03 range of converters. It's essential if mains voltage is over 3% asymmetrical. The device helps protect your drive and motor by absorbing high voltage transients. It adamantly features a steel core with copper wound coils and steel laminations, which can provide additional circuit inductance, reduce line voltage distortions and block damaging voltage harmonics. This model offers flexibility with both vertical and horizontal orientation and includes a fitted temperature contact. It maintains 50% of the nominal inductance at maximum current rating. This choke can be utilized in numerous appliances, including HVAC, pumping, and UPS. It meets IP 10 protection rating as per DIN EN 60 529 specifications. The device enhances power factors and limits short-circuit current.

Contact Us

Email: sales@servosupplier.com
Phone Number: 1-888-551-3082
International: 1-919-443-0207
Fax: 1-919-867-6204

Servo Supplier is not an authorized distributor. We sell new surplus and refurbished products. All warranties are with Servo Supplier and not the manufacturer.

Military Grade
Packaging

30 Day Warranty

Shipping Options

Payment Options

Technical Specifications

Manufacturer

Bosch Rexroth Indramat

Product Code

HNL01.1E-0200-N0125-A-480-NNNN

Compatibility

HCS01, HCS02 and HCS03 range of converters

Mains Voltage Asymmetry

>3%

Connection

Feeding supply system

Protection

Absorbs microsecond transients of high voltage

Material

Steel core with copper wound coils and steel laminations

Function

Absorbs and limits voltage distortions like surges and spikes

Features

Additional circuit inductance capability

Orientation

Supports vertical and horizontal orientation

Terminal Connections (U1, V1, W1)

Maximum connection cross-section of 70mm2

Temperature Contact Fitting

Included

Nominal Inductance

50% at maximum current rating

Application

Between input of a drive and an AC line source to minimize power line distortion

Installation

In HVAC, pumping, UPS and more

Harmonic Mitigation

Low-cost solution

Phase

Three-phase device

Voltage Rating

480VAC

Power Rating

170W

Protection Rating

IP 10 according to DIN EN 60 529 specifications

Additional Options

None

Function

Limits short-circuit current and enhances power factors of the associated power source.
