S image of HNL01.1E-0240-N0106-A-500-NNNN

HNL01.1E-0240-N0106-A-500-NNNN

by Bosch Rexroth Indramat
$0.00 - $0.00
Request a Quote
$0.00 - $0.00
Request a Quote

Request a quote

Add a Message
The HNL01.1E-0240-N0106-A-500-NNNN, made by Bosch Rexroth Indramat, is a mains choke belonging to the HNL01 series. Integrated into the IndraDrive and IndraDyn drive systems, this model aids in automation improvement while maintaining a safe, cost-efficient operation suitable for diverse industries. It alleviates the mains current from harmonics that could interfere with the supply voltage and boosts the continuous DC bus power of converters, satisfying the IEC 61000-3-2 standard. The mains choke is a Variant 1 model with a rectifier supply system and a nominal inductance of 3 x 240 μH. Measuring 193mm x 205mm x 210mm, it operates at a 3-phase AC mains connection voltage from 400 V to 500 V, and a 50 – 60 Hz nominal frequency. The device has an IP 10 protection rating, weighs 17 kg, and is best operated within -10 to 50o C. It pairs well with the HCS03.1E-W0150 converter, having applications in automation technology, wind turbines, and mechanical engineering.

Contact Us

Email: sales@servosupplier.com
Phone Number: 1-888-551-3082
International: 1-919-443-0207
Fax: 1-919-867-6204

Servo Supplier is not an authorized distributor. We sell new surplus and refurbished products. All warranties are with Servo Supplier and not the manufacturer.

Military Grade
Packaging

30 Day Warranty

Shipping Options

Payment Options

Technical Specifications

Manufacturer

Bosch Rexroth Indramat

Product Series

HNL01

Product Model

HNL01.1E-0240-N0106-A-500-NNNN

Primary Function

Relieve the mains current of harmonics, Increase the continuous DC bus power of converters

Complies with Standard

IEC 61000-3-2

Variant

1

Supply System

Rectifier

Nominal Inductance

3 x 240 μH

Dimensions (H x W x D)

193mm x 205mm x 210mm

Power Dissipation

100 W

Operating Voltage

400 V to 500 V (-15 %/+10 %)

Nominal Frequency

50 – 60 Hz (±5 %)

Continuous Current Rating

106 A

Ingress Protection

IP 10

Weight

17 kg

Usage Location

Residential areas only

Mounting Position

Any, if nominal installation altitude does not exceed 1000 m

Operating Temperature

From -10 to 50o C

Compatible Converter

HCS03.1E-W0150

Applications

Drive systems in automation technology, wind turbines, and mechanical engineering
